2-Step Folding

Fold your bike in two simple steps for easy transport. Your perfect companion for the city and travel.

Integrated LED rear light

Efficient motor & support

Tangle-free folding design

C10 E-Bike Facts

Display

brakes

Drive

Battery

Rear light

Bell

Security

Product details

Drive & Legality
Motor

250W high-speed motor

Max. torque

37 Nm

Maximum speed (pedelec)

25 km/h

pedal assist

Intelligent 3-level support

Maximum climbing ability

15°

circuit

Shimano 7-speed gears

Certificates (EU)

SGS, CE, EN15194

Range (depending on support level & conditions)

up to 100 km

Note regarding range

The range depends on factors such as weight, inclines, headwinds, temperature, tire pressure and driving style.

Battery & Charging
Battery capacity

36V / 9.6Ah (345.6 Wh)

Battery type

Lithium-ion drive battery

Battery handling

Removable and lockable

Charging time

4–5 hours

Input voltage

AC 100–240V

Folding Size & Transport
Folded dimensions

815 × 400 × 690 mm

Installation dimensions

1475 × 220 × 690 mm

Wheel size

20 inches

Front wheel system

Quick-release fasteners

pedals

folding pedals

Net weight

18.6 kg (approx. 41.0 lb)

Shipping weight

25.8 kg (approx. 56.9 lb)

Note regarding shipping weight

including packaging, accessories and free gifts

Public transport information

Suitable for bus and train travel (carrying depends on local rules)

Safety & Control
Braking system

hydraulic disc brakes (front & rear)

lighting

LED headlights & taillights with reflector

Display

LED display

App

Connectivity – not currently supported

Tire pressure

35–45 PSI

Operating temperature

-10°C to 45°C

Size & Fit
Measurements & Fit

Recommended height 150 cm (4'11") – 190 cm (6'3")

Maximum load capacity

100 kg (including driver + luggage)

Overhang height

52 cm

saddle height

Min. 75 cm / Max. 100 cm

Included in the scope of delivery

  • C10

  • Key

  • Fenders (Front & Rear)

  • On-board Tool Kit

  • Manual

  • Charger

Size Overview

Recommended: Height: 150 cm (4'11")-190 cm (6'3")

Maximum payload: 100 kg

Folded dimensions: 81.5 x 40 x 69 cm

A. Handlebar height: 69 cm

B. Handlebar reach: 60 cm

C. Handlebar width: 54 cm

D. Overhang height: 52 cm

E. Total length: 147.5 cm

F. Wheelbase: 99 cm

G. Seat tube length: 66 cm

H. Head tube length: 43 cm

I. Chainstay length: 39 cm

J. Min. saddle height: 75 cm

K. Max. saddle height: 100 cm

Is the battery protected against theft? Are there spare keys?

Yes, the battery is lockable and can only be removed with the key. Two keys are included. Please keep the spare key in a safe place.

How heavy is the bicycle actually, including the battery? Will it fit in the trunk of a car or in a camper van?

Thanks to its magnesium alloy frame, this e-bike weighs only 18.6 kg (including battery)! It's significantly lighter than conventional models. When folded, it's very compact and fits perfectly in any car trunk or the rear garage of a camper van.

Is the e-bike legal to ride on public roads in Germany? Do I need a license plate?

The bicycle is equipped with a 250W motor and provides assistance up to 25 km/h (pedelec). It complies with EN15194 standards. When used in pedal-assist mode, no license plate is required. It is ideal for city traffic and commuting.
